Product Parameter
| product model | MT20 |
| Fuel class | diesel oil |
| Driver type | rear-guard |
| Driving mode | Side drive |
| engine type | Yuchai YC6L290-33 medium-cold supercharging |
| engine power | 162KW(290 HP) |
| Transmission model | HW 10 (sinotruk ten gear high and low speed) |
| rear axle | Add to the Mercedes |
| propons | 700T |
| brake mode | Broken gas brake |
| Rear wheel distance | 2430mm |
| front track | 2420mm |
| wheel base | 3200mm |
| The unloading method | Rear unloading, double top (130*1600) |
| discharge height | 4750mm |
| ground clearance | Front axle 250mm rear axle 300mm |
| Front tire model | 1000-20 steel wire tire |
| The rear tire model | 1000-20 steel wire tire (twin tire) |
| overall dimensions of a car | Length 6100mm * width 2550mm* height 2360mm |
| Box size | Length 4200mm * width 2300mm*1000mm |
| Box plate thickness | Base 12mm side is 8mm |
| Direction machine | Mechanical direction machine |
| laminated spring | First 11 pieces * width 90mm *15mm thick second 15 pieces * width 90mm *15mm thick |
| Container volume(m ³) | 9.6 |
| climbing capacity | 15 Degrees |
| Load weight / ton | 25 |
| Exhaust treatment mode | Exhaust purifier |
Features
The rear wheel distance is 2430mm, and the front track is 2420mm, with a wheelbase of 3200mm. The unloading method is rear unloading with double top, with dimensions of 130mm by 1600mm. The discharge height reaches 4750mm, and the ground clearance is 250mm for the front axle and 300mm for the rear axle.
The front tire model is 1000-20 steel wire tire, and the rear tire model is 1000-20 steel wire tire with a twin tire configuration. The overall dimensions of the truck are: Length 6100mm, Width 2550mm, Height 2360mm. The cargo box dimensions are: Length 4200mm, Width 2300mm, Height 1000mm. The box plate thickness is 12mm at the base and 8mm on the sides.
The truck is equipped with a mechanical direction machine for steering, and the laminated spring consists of 11 pieces with a width of 90mm and thickness of 15mm for the first layer, and 15 pieces with a width of 90mm and thickness of 15mm for the second layer. The container volume is 9.6 cubic meters, and the truck has a climbing capacity of up to 15 degrees. It has a maximum load weight capacity of 25 tons and features an exhaust purifier for emission treatment.
Product Details
Frequently Asked Questions (FAQ)
1. Does the vehicle meet safety standards?
Yes, our mining dump trucks meet international safety standards and have undergone a number of rigorous safety tests and certifications.
2. Can I customize the configuration?
Yes, we can customize the configuration according to customer needs to meet the needs of different work scenarios.
3. Which materials are used in body building?
We use high-strength wear-resistant materials to build our bodies, ensuring good durability in harsh working environments.
4. What are the areas covered by after-sales service?
Our extensive after-sales service coverage allows us to support and service customers around the world.
After-Sales Service
We offer a comprehensive after-sales service, including:
1. Give customers comprehensive product training and operation guidance to ensure that customers can correctly use and maintain the dump truck.
2. Provide rapid response and problem solving technical support team to ensure that customers are not troubled in the process of use.
3. Provide original spare parts and maintenance services to ensure that the vehicle can maintain good working condition at any time.
4. Regular maintenance services to extend the life of the vehicle and ensure that its performance is always maintained at its best.
