Product Parameter
| Product model | MT18 |
| Driving style | Side drive spring seat height of seat 1300mm |
| Fuel category | Diesel |
| Engine model | XIchai 6110 |
| Engine power | 155KW(210hp) |
| gearbox model | 10JS90 heavy 10 gear |
| Rear axle | Steyr slowdown Alxe |
| Front axle | Steyr |
| Driv ing type | Rear drive |
| Braking method | Automatically air-cut brake |
| Front wheel track | 2250mm |
| Rear wheel track | 2150mm |
| Wheelbase | 3600mm |
| Frame | Height 200mm * width 60mm* thickness10mm, 10mm steel plate reinforcement on both sides, with bottom beam |
| Unloading method | Rear unloading double support 130*1600mm |
| Front model | 1000-20wire tire |
| Rear mode | 1000-20 wire tire(double tire) |
| Overall dimension | Lenght6300mm*width2250mm*height2150mm |
| Cargo box dimension | Length5500mm*width2100mm*heght950mm Channel steel cargo box |
| Cargo box plate thickness | Bottom 12mm side 6mm |
| Ground clearance | 320mm |
| Steering system | Mechanical steering |
| Leaf springs | Front leaf springs:10pieces*width75mm*thickness15mm Rear leaf springs:13pieces*width90mm*thickness16mm |
| Cargo box volume(m³) | 7.7 |
| Climbi ng ability | 12° |
| Oad capacity /ton | 20 |
| Exhaust gas treatment method, | Exhaust gas purifier |
| Minimum turning radius | 320mm |
Features
The front wheel track measures 2250mm, while the rear wheel track is 2150mm, with a wheelbase of 3600mm. The truck's frame consists of a main beam with a height of 200mm, width 60mm, and thickness 10mm. There is also 10mm steel plate reinforcement on both sides, along with a bottom beam for added strength.
The unloading method is rear unloading with double support, with dimensions of 130mm by 1600mm. The front tires are 1000-20 wire tires, and the rear tires are 1000-20 wire tires with a double tire configuration. The overall dimensions of the truck are: Length 6300mm, Width 2250mm, Height 2150mm.
The cargo box dimensions are: Length 5500mm, Width 2100mm, Height 950mm, and it is made of channel steel. The cargo box plate thickness is 12mm at the bottom and 6mm on the sides. The ground clearance of the truck is 320mm.
The steering system is mechanical steering, and the truck is equipped with 10 front leaf springs with a width of 75mm and thickness of 15mm, as well as 13 rear leaf springs with a width of 90mm and thickness of 16mm. The cargo box has a volume of 7.7 cubic meters, and the truck has a climbing ability of up to 12°. It has a maximum load capacity of 20 tons and features an exhaust gas purifier for emission treatment. The minimum turning radius of the truck is 320mm.
Product Details
Frequently Asked Questions (FAQ)
1. What are the main models and specifications of your mining dump trucks?
Our company produces various models and specifications of mining dump trucks, including large, medium, and small-sized ones. Each model has different loading capacities and dimensions to meet various mining requirements.
2. What types of ores and materials are your mining dump trucks suitable for?
Our mining dump trucks are suitable for all types of ores and materials, including but not limited to coal, iron ore, copper ore, metallic ores, etc. They can also be used for transporting sand, soil, and other materials.
3. What type of engine is used in your mining dump trucks?
Our mining dump trucks are equipped with efficient and reliable diesel engines, ensuring sufficient power and reliability even in harsh mining working conditions.
4. Does your mining dump truck have safety features?
Yes, we place a high emphasis on safety. Our mining dump trucks are equipped with advanced safety features, including brake assistance, anti-lock braking system (ABS), stability control system, etc., to minimize the risk of accidents during operation.
After-Sales Service
We offer a comprehensive after-sales service, including:
1. Provide customers with rich product use training and operation guidance to ensure that they can correctly operate and maintain dump trucks.
2. We provide comprehensive product training and operator instruction to ensure customers can confidently and accurately operate and maintain dump trucks.
3. We provide reliable, high-quality original spare parts and maintenance services to ensure your vehicle is always in top working condition.
4. Regular maintenance services to extend the life of the vehicle and ensure that its performance is always maintained at its best.
